The LED 500 is brighter, and has a greater contrast ratio, while the super bright, maintenance-free 500 lumen LED lamp provides vivid and accurate illumination and lasts up to 30,000 hours. Image controls allow you to rotate, resize, and reverse your picture at the touch of a button, and includes a new feature which automatically adjusts the projected image to be square when being projected higher or lower than the projector.
The keystoning adjustment lets you easily adjust angles and perspective to suit your design. The LED 500 projector has the ability to display digital images from virtually any source, including SD cards, thumb drives, digital cameras, computers, iPads*, and smartphones*.
*May require additional adapter.
- New increased contrast ratio of 15,000:1
- Aspect ratios of both 4:3 and 16:9
- Weighs only 1 lb
- Only 60w of power consumption
- HDMI Outlet for high-definition output
- Up to 1080p resolution
- 500 Lumens bright
- New Rule-Of-Thirds Grid
Technical Specifications
- Projection System: DLP
- Native Resolution: WXGA (1280×800)
- Brightness (ANSI-Lumens): 500
- LED Lamp life: 30,000 Hrs
- Contrast Ratio: 15,000:1
- Focus: Manual
- Zoom: Fixed/software adjustable (USB)
- Aspect Ratio Correction: Native 4:3,Just Scan/Set By Program/16:9/Zoom/Cinema Zoom/Full
- Sound – Speakers: 1W+1W stereo
- Dimension (WxHxD, mm): 6.22 x 4.06 x 1.30 in. (158 x 103 x 33 mm)
- Weight: 1 lb/440g
- Power Consumption: 60W
- Stand by Power: <1W
- Power Supply: AC DC Adaptor (100~240 free voltage), 50/60Hz
Input Signal Compatibility
- Digital (HDMI): 1080p/1080i/720p/576p/480p
- RGB: Up to WSXGA+(1680×1050@60Hz)
- Component Video: 1080p/1080i/720p480p/480i
INPUT/OUTPUT Terminals
- RGB in: 1
- RGB (PC) Audio in: 1
- Audio out: 1 (mini Jack)
- HDMI: 1
- USB: 1 (Type A)
Special Features
- Built in Projection Grids: 19 (New “Rule of Thirds” Grid)
- Grid Access Button on Remote: Y
- Color to Black/White: Y
- Iphone/Ipad/Smart Phone/Pads Compatible: Y (Current Versions, cable adapter required)
- Digital Keystone Correction: Automatic/Manual/Vertical
- Picture Still: Y
- Auto Source Detection: Y
- Quick Power on/off: Y
- Auto Sleep: Y
- Blank Screen: White/Artograph Logo
- Image Flip/Reverse/Rotate: Y
- Color Temperature Control: Y
- Twin XD Image Processors: Y
- Image Control USB: y
- Edge Enhancer: Y (USB)
- Black Level Control: Y
- Expert Control: Y
- Image Control on Screen: Y
- Closed Caption: Y
